The simple interfaces allows cost effective implementation of tunaeble white LED applications outside of central control systems. Using either the remote handset or the common 1-10V and Switch-DIM wall switches, high-end functionality is achieved with realistic budgets on smaller projects.
Suitable for LED panels and downlights – insulated terminal cover with cord restraint:
Use for retrofit upgrades & new luminaire designs.
| Mains Voltage | 220~240VAC 50/60Hz |
| Mains Current | 0.22~0.2A |
| Power factor | 0.95 |
| Max. Effciency | 85% |
| Dialectric Strengt | Input -> Output : 3000VAC |
| Leakage Current | <0.25mA |
| Ripple Current | <3% |
| Uout Max. | 75V |
| Turn-on Time | <0.5s |
| Power/ Current/ Voltage Range | 20W/350mA/10~56V 28W/500mA/10~56V |
| 40W/700mA/10-56V 45W/900mA/10-50V | |
| 42W/1050mA/10~40V 40W/1200mA/10~34V | |
| Case Temp. (Max.) | 85 Degree Celcius |
| Operation Temp | Ta: -20~+50 |
| IP Rating | IP20 |
| Certification | Semko, CB, RMC, CE, EMC |
