Ideally suited to retrofit projects where the luminaire is too small to accomodate the sensor internally, this motion sensor can be completely hidden from view thanks to the penetration properties of microwave sensors. Only a small hole is required to position the daylight sensor.
Total 4 sensors are provided for different applications:
| Mains Voltage | 220~240VAC 50/60Hz |
| Stand-by power | <1W |
| Warming-up | 20s |
| Switched Power | 800W – Capacitive |
| 2000W – Resisitv | |
| Sensor Priciple | High Frequency (Microwave) |
| Operation frequency | 5.8GHz +/-75MHz |
| Transmission power | <0.2mW |
| Detection Range | Max. (OxH): 12m x 3m |
| Detection Angel | 30 ~ 150 Degrees |
| Operation temperature | -20 ~ +60 Degree Celcius |
| IP Rating | IP20 |
